You are here: Home / LVT flooring / Dry Back / Vinyl Floor Dry Back Marble

Vinyl Floor Dry Back Marble

Lvt vinyl Flooring 2mm thick dry back, 100% virgin material, Eco-friendly material, . 100% waterproof can be used for bathroom and kitchen. lvt bathroom flooring, lvt kitchen flooring, CE certificate lvt

Quantity:
  • LVT2-EC8107
  • Eco Home

LVT structure




LVT flooring specification


Material 100% virgin material
Thickness 2mm(can be custom made3.5mm-5mm)
Size 183*1220mm(152*914mm, 229*1220mm, or custom make)
Top wearlayer 0.15mm/6mil ( can be custom make 0.07mm-0.6mm)
warranty 7 years for residental
Color Hundreds of color designs available
Installation  Dryback
Surface treatment UV coating
Special treatment Deep embossed EIR,
Design style wood grain, stone, marble, carpet



LVT flooring packing

Pcs/box 24pcs
weight/box 19.2kgs
boxes/pallet 60 boxes
Pallet size 1240*990*980mm
Pallets/20'FCL 18 pallets
Sqm/20'FCL 5786 square meters
Weight(kgs)/20'FCL 20736kgs


op

KW8112-1

EC8112


KW8116-1-1

EC8116


KW8117-1-1

EC8117


KW8115-2-1

EC8115

KW8111-1

EC8111


KW8113-1-1

EC8113


KW8114-2-1

EC8114


KW8107-1

EC8107

KW8110-1

EC8110


KW8106-1

EC8106


KW8105-1

EC8105


KW8102-1

EC8102


Popular size For LVT

LVT SIZE


Installation Methods for LVT flooring

LVT installation


  100% waterproof, Stain-resistance

  Fireproof

  Anti-Scratch

  Easy to Installation


H15e8dd52da6b4c5c8f00ff324254bb176.jpg_



Physical Requirements


Characteristics Test Method Test requirements Verdict
图片1 Size ≤305mm EN427 ± 0.4mm pass
305mm˂size˂457mm EN427 ± 0.45mm pass
457mm˂size˂610mm EN427 ± 0.50mm pass
610mm˂plank length ˂1220mm EN427 ± 1.5mm pass
Plank length ≥1220mm EN427 ± 2.0mm pass

Squareness
≤ 0.25mm pass

Thickness, product without foam EN428 ± 0.13mm pass

Thickness, product with foam EN428 ± 2.0mm pass

Thickness,wearlayer EN429
pass

Density  kgs/m³
1.8
图片2 80℃ 6H Heating Curling
lengthwise ±1mm 0.05-0.07mm

Horizontal  ±1mm 0.05-0.07mm
80℃ 6H Heating shrinkage
lengthwise <0.1% 0.03-0.05%

Horizontal  <0.1% 0.04-0.06%
一25℃ 6H Low Temperature Warping
lengthwise ±1mm 0.1-0.15mm

Horizontal  ±1mm 0.1-0.15mm

Locking Strength
lengthwise >180N 190-210N


Horizontal >200N 220-240N

 Peel Strength
Lengthwise >100N/5cm 107-121N


Horizontal   >100N/5CM 138-144N

Gapping
≤0.10 0.01-0.03mm

Difference of Height
≤0.10 0.01-0.03mm
图片3 Scratch Resistant
≥2800g pass
Martindale
≤2  pass
Foot Wheelchair test EN425 5000rpm pass

Residual Imprint  EN 433 ≤0.12 mm pass

Characteristics

waterproof 100% water proof

IPX8
fireproof1 Fire Resistance EN13501-1
class Bfi-S1
VOC Core free of Formaldehyde EN717-1
E0
slip resistance Slip Resistance EN51 130

Class DS

R9

soundproof Soundproof EN ISO 717/2
63
chemical Chemical Resistance EN423
Class 0
